Stainless Steel Forged Hook Bolts

Metric forged hook bolts & countersunk forged hook bolts supplier

Table of Content

Fasteners Types
Stainless Steel Forged Hook Bolts Manufacturers in India

stainless steel hex bolt

metric forged hook bolts Manufacturer in India

Metric forged hook bolts

extra large forged hook bolts manufacturers in India

Extra large forged hook bolts

Stainless Steel Forged Hook Bolts Specification

Product name Stainless Steel Forged Hook Bolts
Place of Ori India
Standard ISO 4017, DIN931, GB5783, DIN, ASTM, ANSI, JIS, EN, AS
DIN Standard B.S. DIN933 DIN931 DIN934 DIN912 DIN603 DIN6923
Surface treatment
 Passivation /pl
Stainless Steel Hanger Bolts Size M2 – M100
Stainless Steel Hanger Bolts Diameter M3-M60
Stainless Steel Hanger Bolts Length 6mm-500mm
Head Hex, Square, Round, Hex flange, Flat, T-head & Triangular etc
Neck type Hex, Square, Triangular, Oval & Knurled etc
Drive type Phil, Slotted, Hex socket, Torx & square slot etc
Stainless Steel Hanger Bolts Application Wind tower, Nuclear power, Railway, Automotive industry, Construction, Electronic industry
Dimensions ASME B18.6.3 **Exception: screws 6 inches and shorter are fully threaded.
Drive Style Type I
Stainless Steel Hanger Bolts Material 18-8 Stainless Steel, stainless steel ss 304/ SS316 A2/A4, SS201, SS303, SS304, SS316, SS316L, SS904L, A2-70; A4-70; A4-80
Thread Requirements ASME B1.1, UNC & UNF, Class 2A (Fastenal will inspect and accept parts with a 1A no-go gauge)
Finish Per ASTM A380/A380M
Finishing Zinc Plated (Yellow, White, Blue, Black), Hop Dip Galvanized (HDG) phosphorization, Black Oxide, Geomet, Dacroment, anodization, Nickel plated, Zinc-Nickel plated, Brass Plated, Tin Plated, Black Plated, Copper Plated, Gold Plated, Salt fog test
Stock Products Stainless steel: All DIN, GB Standard and part ASNI standard stainless steel Hanger Bolts, Hanger: ISO7380, DIN7981, DIN7982, DIN916, DIN913, DIN7985, DIN912
Production technology Cold Forged
Manufacturing Process Wire Drawing, Cold Heading, Insert tapping, Heat Treatment, Surface Plating, Inspection, Packing
MOQ 10 pieces
Delivery time Regular product is about 7-15 days, custom product will according to special requirement
Others OEM, ODM, ±0.03MM tolerance
Surface treatment of stainless steel Hanger Bolts
  • Passivation
  • Polish
  • Anodizing
  • Sand blasting
  • Electroplating (color, blue, white, black zinc, Ni, Cr, tin, copper, silver)
  • Black oxide coating
  • Heat-disposing
  • Hot-dip galvanizing
  • Rust preventive oil
Coatings Black Oxide, Cadmium, Galvanized, Teflon, Xylan, Zinc, Others Upon Request
Tolerance of stainless steel Hanger Bolts +/-0.01mm to +/-0.05mm
Samples Yes
Production Capacity 2,700,000 pieces per month
Payment Terms T/T, Paypal, Western Union, L/C or Trade Assurance 30% deposit & balance before shipping

Forged Hook Bolts Weight Chart

Stainless steel forged hook bolts

Forged Hook Bolts Dimensions

Stainless steel hook bolts dimension
Length
(B) in Inch		 Outside Eye Diameter
(C) in Inch		 Inside Eye Diameter
(D) in Inch		 Overall Length*
(E) in Inch		 Thread Length*
(F) in Inch
1/4-20 (A)
2 1 1/2 3-7/32 1-1/2
3 1 1/2 4-7/32 1-1/2
4 1 1/2 5-7/32 2
5 1 1/2 6-7/32 2-1/2
6 1 1/2 7-7/32 3
5/16-18 (A)
2-1/4 1-1/4 5/8 3-23/32 1-1/2
3-1/4 1-1/4 5/8 4-23/32 1-1/2
4-1/4 1-1/4 5/8 5-23/32 2-1/2
5 1-1/4 5/8 6-15/32 2-1/2
6 1-1/4 5/8 7-15/32 3
3/8-16 (A)
2-1/2 1-1/2 3/4 4-1/4 1-1/2
3 1-1/2 3/4 4-3/4 1-1/2
4 1-1/2 3/4 5-3/4 2
4-1/4 1-1/2 3/4 6 2
4-1/2 1-1/2 3/4 6-1/4 3
5 1-1/2 3/4 6-3/4 3
6 1-1/2 3/4 7-3/4 3
8 1-1/2 3/4 9-3/4 4
10 1-1/2 3/4 11-3/4 4
1/2-13 (A)
2 2 1 4-3/16 1-5/8
3-1/4 2 1 5-7/16 2
4 2 1 6-3/16 3
4-1/2 2 1 6-11/16 3
6 2 1 8-3/16 3
8 2 1 10-3/16 4
10 2 1 12-3/16 4
12 2 1 14-3/16 4
5/8-11 (A)
4 2-1/2 1-3/8 6-5/8 3
4-1/2 2-1/2 1-3/8 7-1/8 3
6 2-1/2 1-3/8 8-5/8 3
8 2-1/2 1-3/8 10-5/8 4
10 2-1/2 1-3/8 12-5/8 4
12 2-1/2 1-3/8 14-5/8 4
15 2-1/2 1-3/8 17-5/8 6
18 2-1/2 1-3/8 20-5/8 6
24 2-1/2 1-3/8 26-5/8 6
3/4-10 (A)
4 2-13/16 1-1/2 6-7/8 3
4-1/2 2-13/16 1-1/2 7-3/8 3
6 2-13/16 1-1/2 8-7/8 3
8 2-13/16 1-1/2 10-7/8 4
10 2-13/16 1-1/2 12-7/8 4
12 2-13/16 1-1/2 14-7/8 4
15 2-13/16 1-1/2 17-7/8 6
18 2-13/16 1-1/2 20-7/8 6
24 2-13/16 1-1/2 26-7/8 6
7/8-9 (A)
5 3-1/2 1-3/4 8-1/4 3
6 3-1/2 1-3/4 9-1/4 3
8 3-1/2 1-3/4 11-1/4 4
10 3-1/2 1-3/4 13-1/4 4
12 3-1/2 1-3/4 15-1/4 4
18 3-1/2 1-3/4 21-1/4 6
24 3-1/2 1-3/4 27-1/4 6
1-8 (A)
6 4 2 9-5/8 3
8 4 2 11-5/8 4
10 4 2 13-5/8 4
12 4 2 15-5/8 4
15 4 2 18-5/8 6
18 4 2 21-5/8 6
24 4 2 27-5/8 6
1-1/4-7 (A)
6 4-7/16 2-3/16 10-1/2 3
8 4-7/16 2-3/16 12-1/2 4
12 4-7/16 2-3/16 16-1/2 4
18 4-7/16 2-3/16 22-1/2 6
24 4-7/16 2-3/16 28-1/2 6
1-1/2-6 (A)
6 5-3/16 2-1/2 11-1/4 3
12 5-3/16 2-1/2 17-1/4 4
18 5-3/16 2-1/2 23-1/4 6
24 5-3/16 2-1/2 29-1/4 6
2-4-1/2 (A)
12 6-7/8 3-1/4 19 4
* Overall length and thread length for imported eye bolts are approximate. Their values may differ from those listed in this table.

Price List of SS Forged Hook Bolts

Product Price in USD
Forged Concrete Anchor Bolt with Hook US $0.6
Drop Forged Eye Bolt US $0.55

Stainless Steel Forged Hook Bolts Stock list

countersunk forged hook bolts decorative forged hook bolts
metric forged hook bolts heavy forged hook bolts
self tapping forged hook bolts exterior forged hook bolts
tamper proof forged hook bolts extra large forged hook bolts
imperial forged hook bolts flat forged hook bolts
grade 8 forged hook bolts fine threaded forged hook bolts
hex socket forged hook bolts security forged hook bolts
extra large forged hook bolts custom forged hook bolts
