No 10 Stainless Steel Screws

Quality 10 stainless steel screws manufacturers in India

Table of Content

Fasteners Types
No 10 Stainless steel screws Manufacturers in India

No 10 Stainless steel screws

Number 10 Countersunk Stainless Steel Screws Manufacturer in India

A4 Countersunk Stainless Steel Screws

#10 slot and point screws manufacturers in India

#10 slot and point Screws

Specification of No 10 Stainless steel screws

Product name No 10 Stainless Steel Screws
Place of Origin India
Standard ISO 7380, DIN, ASTM, ANSI, JIS, EN, AS, GB
Surface treatment
Passivation /plain
No 10 Stainless Steel Screws Size M2 – M100
Type Pan/ Round/ Oval/ countersunk/ Truss head
Head Pan head, flat head, oval head, hex head, phillips head
No 10 Stainless Steel Screws Usage Electric Heating, Machine
Dimensions ASME B18.6.3 **Exception: screws 6 inches and shorter are fully threaded.
Drive Style Type I
No 10 Stainless Steel Screws Material 18-8 Stainless Steel, stainless steel ss 304/ SS316 A2/A4, SS201, SS303, SS304, SS316, SS316L, SS904L, A2-70, A4-80
Thread Requirements ASME B1.1, UNC & UNF, Class 2A (Fastenal will inspect and accept parts with a 1A no-go gauge)
Finish Per ASTM A380/A380M
Finishing Zinc Plated(Yellow, White, Blue, Black), Hop Dip Galvanized (HDG) phosphorization, Black Oxide, Geomet, Dacroment, anodization, Nickel plated, Zinc-Nickel plated, Brass Plated, Tin Plated, Black Plated, Copper Plated, Gold Plated, Salt fog test
Stock Products Stainless steel: All DIN, GB Standard and part ASNI standard No 10 Stainless Steel Screws, Example: ISO7380, DIN7981, DIN7982, DIN916, DIN913, DIN7985, DIN912
Specialized in Stainless steel CSK philip screw, CSK socket screw, Pan head Ph screw, Pan head socket screw, Socket cap head screw, set screw, Pan head torx screw, CSK head trox screw, Wood screw
Production technology Cold Forged
Manufacturing Process Wire Drawing, Cold Heading, Insert tapping, Heat Treatment, Surface Plating, Inspection, Packing
MOQ 10 pieces
Delivery time Regular product is about 7-15 days, custom product will according to special requirement
Others OEM, ODM, ±0.03MM tolerance
Surface treatment of No 10 Stainless Steel Screws
  • Passivation
  • Polish
  • Anodizing
  • Sand blasting
  • Electroplating (color, blue, white, black zinc, Ni, Cr, tin, copper, silver)
  • Black oxide coating
  • Heat-disposing
  • Hot-dip galvanizing
  • Rust preventive oil
Tolerance of No 10 Stainless Steel Screws +/-0.01mm to +/-0.05mm
Samples Yes
Production Capacity 2,700,000 pieces per month
Payment Terms T/T, Paypal, Western Union, L/C or Trade Assurance 30% deposit & balance before shipping

No 10 SS Screws Weight Chart

LENGTHS
#2
#3
#4
#5
#6
#8
#10
#12
1/4″
5/16″
3/8″
1/8
 0.40 0.55 0.70 1.1 1.4 — — — — — —
3/16
 0.50 0.70 0.90 1.2 1.5 2.5 3.9 — — — —
1/4
 0.60 0.80 1.00 1.4 1.7 2.8 4.3 5.6 8.5 — —
5/16
 0.60 0.90 1.20 1.5 1.9 3.1 4.6 6.1 9.1 16.7 —
3/8
 0.70 0.90 1.30 1.7 2.1 3.4 5.0 6.5 9.8 17.7 29.2
7/16
 0.80 1.00 1.50 1.9 2.2 3.6 5.4 6.9 10.4 18.8 30.7
1/2
 0.80 1.10 1.60 2.0 2.4 3.9 5.8 7.4 11.1 19.8 32.2
9/16
 0.90 1.20 1.70 2.2 2.6 4.2 6.2 7.8 11.7 20.9 33.6
5/8
 1.00 1.30 1.80 2.3 2.8 4.5 6.6 8.3 12.4 21.9 35.1
3/4
 1.10 1.50 2.10 2.6 3.2 5.0 7.3 9.2 13.6 24.0 38.0
7/8
 1.30 1.70 2.30 3.0 3.5 5.6 8.1 10.1 14.9 26.1 41.0
1″
 1.40 1.90 2.50 3.4 3.9 6.2 8.9 11.0 16.1 28.8 44.0
1-1/8″
 1.50 2.00 2.80 3.8 4.3 6.7 9.6 11.9 17.4 30.2 47.0
1-1/4″
 1.60 2.20 3.00 4.1 4.6 7.3 10.4 12.8 18.7 32.3 49.8
1-1/2″
 1.80 2.50 3.50 4.7 5.3 8.3 11.9 14.7 21.2 36.5 55.8
1-3/4″
 2.10 2.90 4.00 5.3 6.1 9.4 13.5 16.5 23.7 40.7 61.7
2″
 2.40 3.30 4.50 6.0 6.8 10.6 15.0 18.3 26.2 44.8 67.6
2-1/4″
 2.60 3.60 5.00 6.7 7.6 11.8 16.6 20.1 28.8 19.0 73.5
2-1/2″
 2.80 3.90 5.50 7.3 8.3 12.9 18.1 22.0 31.3 53.2 79.5
2-3/4″
 3.10 4.30 6.00 7.9 9.1 13.9 19.7 23.8 33.9 57.3 85.3
3″
 3.40 4.70 6.50 8.6 9.8 15.0 21.2 25.6 36.4 61.5 91.3
* Above are approximate weights and are based on pan head machine screws

No 10 Stainless Steel Screws Dimensions

Dimensions of No 10 Stainless Steel pan head screw
Nominal
Screw
Size		 Number
Of Thread
Starts		 D A H P Recommened
Hole Size
Outside
Diameter		 Head
Diameter		 Head
Height		 Pilot
Diameter		 Drill Size
No.		 Hole
Diameter
Max. Min. Max. Min. Max. Min. Max. Min.
00
0
2
4		 6
6
8
7		 0.060
0.075
0.100
0.116		 0.057
0.072
0.097
0.112		 0.099
0.127
0.162
0.211		 0.090
0.118
0.146
0.193		 0.034
0.049
0.069
0.086		 0.026
0.041
0.059
0.075		 0.049
0.063
0.083
0.096		 0.046
0.060
0.080
0.092		 55
51
44
37		 0.052
0.067
0.086
0.104
6
7
8
10		 7
8
8
8		 0.140
0.154
0.167
0.182		 0.136
0.150
0.162
0.177		 0.260
0.285
0.309
0.359		 0.240
0.264
0.287
0.334		 0.103
0.111
0.120
0.137		 0.091
0.099
0.107
0.123		 0.116
0.126
0.136
0.150		 0.112
0.122
0.132
0.146		 31
29
27
20		 0.120
0.136
0.144
0.161
12
14		 8
9		 0.212
0.242		 0.206
0.236		 0.408
0.457		 0.382
0.429		 0.153
0.170		 0.139
0.155		 0.177
0.202		 0.173
0.198		 11
2		 0.191
0.221

Price List of No 10 SS Screws

M2 x 6mm, Pack 100 €13.10/£11.53
M2 x 16mm, Pack 100 €20.50/£18.04
M3 x 6mm, Pack 100 €5.00/£4.40
M2 x 12mm, Pack 100 €19.00/£16.72
M4 x 8mm, Pack 100 €10.50/£9.24
M5 x 12mm, Pack 100 €6.33/£5.57
M5 x 12mm, Pack 15 €2.50/£2.20
M4 x 12mm, Pack 10 €2.50/£2.20
M6 x 12mm, Pack 100 €10.28/£9.05
