A4 Stainless Steel Screws

A4 stainless steel wood screws manufacturer

Table of Content

Fasteners Types
A4 Stainless Steel Screws Manufacturers in India

A4 Stainless Steel Screws

A4 Low Form Stainless Steel Screws manufacturers in India

A4 Low Form Stainless Steel Screws

A4 Countersunk Stainless Steel Screws Manufacturer in India

A4 Countersunk Stainless Steel Screws

Specification of A4 Stainless steel screws

Product name A4 Stainless Steel Screws
Place of Origin India
Standard ISO 7380, DIN, ASTM, ANSI, JIS, EN, AS, GB
Surface treatment
Passivation /plain
A4 Stainless Steel Screws Size M2 – M100
Type Pan/ Round/ Oval/ countersunk/ Truss head
Head Pan head, flat head, oval head, hex head, phillips head
A4 Stainless Steel Screws Usage Electric Heating, Machine
Dimensions ASME B18.6.3 **Exception: screws 6 inches and shorter are fully threaded.
Drive Style Type I
A4 Stainless Steel Screws Material 18-8 Stainless Steel, stainless steel ss 304/ SS316 A2/A4, SS201, SS303, SS304, SS316, SS316L, SS904L, A2-70, A4-80
Thread Requirements ASME B1.1, UNC & UNF, Class 2A (Fastenal will inspect and accept parts with a 1A no-go gauge)
Finish Per ASTM A380/A380M
Finishing Zinc Plated(Yellow, White, Blue, Black), Hop Dip Galvanized (HDG) phosphorization, Black Oxide, Geomet, Dacroment, anodization, Nickel plated, Zinc-Nickel plated, Brass Plated, Tin Plated, Black Plated, Copper Plated, Gold Plated, Salt fog test
Stock Products Stainless steel: All DIN, GB Standard and part ASNI standard A4 Stainless Steel Screws, Example: ISO7380, DIN7981, DIN7982, DIN916, DIN913, DIN7985, DIN912
Specialized in Stainless steel CSK philip screw, CSK socket screw, Pan head Ph screw, Pan head socket screw, Socket cap head screw, set screw, Pan head torx screw, CSK head trox screw, Wood screw
Production technology Cold Forged
Manufacturing Process Wire Drawing, Cold Heading, Insert tapping, Heat Treatment, Surface Plating, Inspection, Packing
MOQ 10 pieces
Delivery time Regular product is about 7-15 days, custom product will according to special requirement
Others OEM, ODM, ±0.03MM tolerance
Surface treatment of A4 Stainless Steel Screws
  • Passivation
  • Polish
  • Anodizing
  • Sand blasting
  • Electroplating (color, blue, white, black zinc, Ni, Cr, tin, copper, silver)
  • Black oxide coating
  • Heat-disposing
  • Hot-dip galvanizing
  • Rust preventive oil
Tolerance of A4 Stainless Steel Screws +/-0.01mm to +/-0.05mm
Samples Yes
Production Capacity 2,700,000 pieces per month
Payment Terms T/T, Paypal, Western Union, L/C or Trade Assurance 30% deposit & balance before shipping

A4 SS Screws Weight Chart

LENGTHS
#2
#3
#4
#5
#6
#8
#10
#12
1/4″
5/16″
3/8″
1/8
 0.40 0.55 0.70 1.1 1.4 — — — — — —
3/16
 0.50 0.70 0.90 1.2 1.5 2.5 3.9 — — — —
1/4
 0.60 0.80 1.00 1.4 1.7 2.8 4.3 5.6 8.5 — —
5/16
 0.60 0.90 1.20 1.5 1.9 3.1 4.6 6.1 9.1 16.7 —
3/8
 0.70 0.90 1.30 1.7 2.1 3.4 5.0 6.5 9.8 17.7 29.2
7/16
 0.80 1.00 1.50 1.9 2.2 3.6 5.4 6.9 10.4 18.8 30.7
1/2
 0.80 1.10 1.60 2.0 2.4 3.9 5.8 7.4 11.1 19.8 32.2
9/16
 0.90 1.20 1.70 2.2 2.6 4.2 6.2 7.8 11.7 20.9 33.6
5/8
 1.00 1.30 1.80 2.3 2.8 4.5 6.6 8.3 12.4 21.9 35.1
3/4
 1.10 1.50 2.10 2.6 3.2 5.0 7.3 9.2 13.6 24.0 38.0
7/8
 1.30 1.70 2.30 3.0 3.5 5.6 8.1 10.1 14.9 26.1 41.0
1″
 1.40 1.90 2.50 3.4 3.9 6.2 8.9 11.0 16.1 28.8 44.0
1-1/8″
 1.50 2.00 2.80 3.8 4.3 6.7 9.6 11.9 17.4 30.2 47.0
1-1/4″
 1.60 2.20 3.00 4.1 4.6 7.3 10.4 12.8 18.7 32.3 49.8
1-1/2″
 1.80 2.50 3.50 4.7 5.3 8.3 11.9 14.7 21.2 36.5 55.8
1-3/4″
 2.10 2.90 4.00 5.3 6.1 9.4 13.5 16.5 23.7 40.7 61.7
2″
 2.40 3.30 4.50 6.0 6.8 10.6 15.0 18.3 26.2 44.8 67.6
2-1/4″
 2.60 3.60 5.00 6.7 7.6 11.8 16.6 20.1 28.8 19.0 73.5
2-1/2″
 2.80 3.90 5.50 7.3 8.3 12.9 18.1 22.0 31.3 53.2 79.5
2-3/4″
 3.10 4.30 6.00 7.9 9.1 13.9 19.7 23.8 33.9 57.3 85.3
3″
 3.40 4.70 6.50 8.6 9.8 15.0 21.2 25.6 36.4 61.5 91.3
* Above are approximate weights and are based on pan head machine screws

A4 Stainless Steel Screws Dimensions

Dimensions of A4 Stainless Steel pan head screw A4 combination drive pan head screws

Price List of A4 Stainless Steel Screws

M2 x 6mm, Pack 100 €13.10/£11.53
M2 x 16mm, Pack 100 €20.50/£18.04
M3 x 6mm, Pack 100 €5.00/£4.40
M2 x 12mm, Pack 100 €19.00/£16.72
M4 x 8mm, Pack 100 €10.50/£9.24
M5 x 12mm, Pack 100 €6.33/£5.57
